Apple Studio Display XDR review: Expensive, but theres no monitor like it

It’s hard for most people to justify spending $3,299 on a monitor, but creative pros will gladly do so if it makes their jobs easier. Apple’s 27-inch 5K Studio Display XDR is aimed straight at those folks and it costs considerably less than the company’s previous high-end monitor, the 6K Pro Display XDR.

Thanks to the Mini LED IPS panel, the Studio Display XDR has higher brightness and color accuracy than nearly any other monitor on the market. It also has tech that boosts contrast to outperform similar displays. With its unique combination of features, the Studio Display XDR isn’t as overpriced as you might think, and it has high appeal for me as a video editor. I do, however, wish it was bigger.

Design and features

If you’re familiar with Apple’s previous Studio Display, you’ll have a good idea of the Studio Display XDR’s design. The body has a high-quality brushed aluminum finish, with small holes across the top and bottom designed to vent heat from the built-in, nearly silent fan.

It has enough internal hardware to be a standalone computer, as it’s equipped with an A19 Pro processor and 12GB (!) of RAM — more than Apple’s new MacBook Neo laptop. That extra horsepower is required for all of the image processing, dimming algorithms, webcam operation and HDR tone-mapping.

A tilt- and height-adjustable stand was a cool $1,000 option on the more expensive Pro Display XDR, but it’s thankfully included with this new model. The stand’s motion is delightfully smooth, with just a slight amount of pressure required to move it up and down. However, it only offers four inches of height adjustment and no ability to swivel the screen. You can also get this monitor with a VESA mount instead at the same base price, in case you want to mount it on your own stand or a wall.

The Studio Display XDR comes with two high-speed 120Gbps Thunderbolt ports to connect your Mac, storage or another display, along with two 10Gbps USB-C inputs, but there’s no HDMI port in sight. One of the Thunderbolt ports supports 140W charging, which can replenish a 16-inch MacBook Pro at the maximum possible speed. Apple has also thrown in a Thunderbolt 5 cable that is thicker than any USB-C cable I’ve seen. The power cable also looks nice, but is not removable.

Up front, the monitor has surprisingly thick bezels (0.75 inches) that detract from the otherwise sleek design. In comparison, my ASUS ProArt PA32UCX display’s bezels are just a quarter of an inch thin. Built into the top bezel is a 12-megapixel camera with Apple’s Center Stage feature that keeps your face front and center during Zoom calls. Note that if you prefer less glare, you can get nano-texturing on the display for an extra $300.

The Studio Display XDR is designed mainly for use with Macs, and recent ones at that. Mac models with M1, M1 Pro, M1 Max, M1 Ultra, M2 and M3 chips only support this monitor at up to 60Hz — not the maximum 120Hz. Apple doesn’t mention support for Intel Macs or Windows PCs, but I tested the monitor on both and it worked fine at the 60Hz limit.

Image quality

Apple has largely stuck with Mini LED and quantum dot technology for its MacBook Pro laptop screens and monitors because of the higher brightness levels and lack of “burn in” compared to OLED displays. The tradeoff for that is lower contrast, as I explained here. Mini LED displays also show a phenomenon called “blooming” not present in OLED panels, which is caused by light bleed from neighboring pixels.

However, Apple has largely solved those issues on the Studio Display XDR by boosting the number of local dimming zones (individual LED backlights) to 2,304, four times as many as the XDR Display Pro. That allows not only more brightness, but higher contrast and minimal blooming.

This model doesn’t offer 6K like the Pro Display XDR, but its 5K resolution is still higher than most rivals. That’s a big benefit for designers, animators, photographers and others who want the sharpest image possible. The higher 120Hz refresh rate is also easier on the eyes and better for gaming. However, creators used to screens that are 32 inches or larger may be turned off by the Studio Display XDR’s smaller size.

Brightness is where this monitor really shines; XDR stands for “extended dynamic range,” after all. Apple promises a peak level of 1,000 nits in SDR and 2,000 nits in HDR mode. I was able to verify those claims: I measured 1,991 nits on a Calibrite colorimeter in a 25 percent window and 988 nits at full screen — making this the brightest monitor I’ve ever tested. When I watched HDR material on YouTube and Netflix graded for brightness levels over 1,000 nits, I didn’t see any of the highlight clipping that occurs on my 1,400-nit ASUS ProArt display.

What’s more, the Studio Display XDR’s 1,000,000:1 contrast ratio is among the highest of any non-OLED display (though not infinite like OLED displays). On top of that, I saw virtually no blooming with bright light points against black. Finally, this monitor has the best off-axis performance I’ve seen with very little drop in gamma even at fairly sharp viewing angles.

Color accuracy is also a strong point. Apple promises a Delta E of less than one, and my measurements (around 0.8) bore that out. And like the Pro Display XDR, this model has a true 10-bit IPS panel, which means you get one billion colors total. Apple notes that the Studio Display XDR is the first Apple monitor to include both the P3 wide color Adobe RGB primaries, unlocking “deeper greens and cyans than P3 alone,” it said in a white paper. For HDR work, it covers 81 percent of the challenging BT.2020 color gamut, which is excellent though a bit below some OLED monitors.

The Studio Display XDR can handle a variety of work thanks to the huge number of color profiles included with the display, which total 16 in all. Those include HDR profiles, P3 Digital Cinema, Photography, HDR photography, Design and Print and even Medical Imaging. To verify that, I tested it with several apps including Lightroom Classic and DaVinci Resolve, and was astounded by the color accuracy and brightness. Unlike some rivals, most notably ASUS, it doesn’t support Dolby Vision, however.

On top of being an excellent content creation monitor, the Studio Display XDR is solid for entertainment and gaming. I watched scenes from movies and TV shows including Spider-Man No Way Home, Game of Thrones and Tenet, and enjoyed the extra brightness, high color accuracy and contrast ratio that allowed me to see what the heck was going on in the Night King battle in GoT. For gaming I tried Cyberpunk 2077 for Mac, and the 120Hz refresh rate (it also supports Adaptive Sync 47-120Hz refresh rates), along with the brightness and color accuracy, makes it Apple’s best display yet for gaming.

Camera and speakers

Though it has the same name, the 12MP Center Stage webcam is much improved from the previous Studio Display. The resolution may be the same, but the new camera provides a much brighter and sharper image in dim conditions. However, to use the Desk View feature I needed to tilt the screen forward more than I’d like.

The built-in six speaker sound system is surprisingly good too, offering what is easily the best sound I’ve ever heard coming from a monitor. It supports Spatial Audio and Dolby Atmos sound as before, but now offers deeper bass. It still can’t match a dedicated soundbar or separate speakers, of course, but the audio on this display is clear and surprisingly loud.

Wrap-up

As I said at the outset of this review, Apple’s Studio Display XDR is overpriced, but not by a lot. It’s the brightest monitor I’ve measured and has among the highest number of dimming zones for a Mini LED display for maximum contrast. At the same time, it offers superb color accuracy out of the box, supports up to 5K 120Hz resolution and oozes quality. Few monitors in any category and price range, whether Mini LED or OLED, can boast all of that.

There are cheaper options that can do some of those things. If you prefer OLED, the ASUS ProArt PA27 4K model offers 1,000 nits of max brightness and similar color performance, with better contrast and double the refresh rate for $1,299. And if you want a bigger display that’s nearly as bright as the Studio Display XDR, ASUS also makes the $3,199 PA32UCG-K Mini LED 32-inch monitor with 1,600 nits peak brightness, albeit with half the number of dimming zones.

However, if you require the best image quality possible and don’t mind a 27-inch display, Apple’s Studio Display is the best choice. It will never be a mainstream product, but thanks to its versatility and better value than the Pro Display XDR, I think it will be a surprisingly popular option.
